Product overview
HD AFFF 6-C6 is an aqueous film-forming foam concentrate for hydrocarbon fire protection. The manufacturer specifies a 6% solution with compatible water and foam equipment. The selected concentrate, proportioner and discharge device must be checked as a complete system. The 6-C6 formulation is described for hydrocarbon hazards; it is not presented here as an alcohol-resistant polar-solvent foam.
Technical specifications
| Manufacturer | HD FIRE PROTECT |
|---|---|
| Product / system | AFFF 6-C6 |
| Product type | Foam Systems |
| Product family | Foam Concentrates |
| Subcategory | Foam Concentrates |
| Concentrate type | Aqueous film-forming foam (AFFF), C6 formulation |
| Mixing ratio | 6% |
| Water compatibility | Fresh / sea-salt / hard water |
| Appearance | Clear to amber liquid |
| Specific gravity at 20°C | 1.01 ± 0.02 |
| pH at 20°C | 8.0 ± 1.0 |
| Viscosity at 20°C | Less than 2 cSt |
| Pour point | Flows at −2°C; freeze-protected type separately selected |
| Typical expansion | More than 7; equipment and system conditions apply |
| Typical 25% drainage | More than 2 minutes 30 seconds; equipment and system conditions apply |
| Manufacturer-listed approvals | UL Listed to UL 162 |
| Packaging options | 20-litre cans / 200-litre drums / 1,000-litre totes / bulk |
Approval scope applies to the listed system and component configuration. Confirm the selected equipment against the current manufacturer document and project submittal.
Key features
- Concentrate type: Aqueous film-forming foam (AFFF), C6 formulation
- Mixing ratio: 6%
- Water compatibility: Fresh / sea-salt / hard water
Applications
Class B hydrocarbon hazards such as fuel storage, process areas, refineries, terminals and aviation-fuel facilities within the approved application scope.
Selection and project integration
Share the system drawings, protected hazard, equipment schedule and project specification with UDCT. Product selection should establish the required flow and pressure, pipework connections, materials, installation orientation and compatible components. Check the precise approval scope for the selected model, size and configuration against the current manufacturer documentation.
The product reference does not replace hydraulic calculations or the approved system design. For foam equipment, confirm the concentrate, proportioning range and discharge-device compatibility as one system. Use the manufacturer instructions for installation, commissioning and maintenance, and confirm the supplied configuration with UDCT before procurement.
