Product overview
The HD Fire Dry Pilot Actuator is part of the manufacturer's deluge valves & skids range. It should be selected as a coordinated component of the relevant protection system. Review the construction, connection and rating data below against the exact installation and manufacturer documentation.
Technical specifications
| Manufacturer | HD FIRE PROTECT |
|---|---|
| Product / system | Dry Pilot Actuator |
| Product type | Water-Based Systems |
| Product family | Deluge Valves & Skids |
| Subcategory | Deluge / Accessories |
| Model / material options | H2: stainless steel (standard); H1: bronze (optional) |
| Connection | 1/2 inch BSPT |
| Maximum operating water pressure | 250 psi (17.5 kg/sq.cm, as stated in the manufacturer sheet) |
| Finish | Red, RAL 3001 |
| Listing scope | Part of the HD UL-listed deluge trim |
| Compatible deluge models | H2, H3 and H5 |
Key features
- Defined pipework connection interface
Applications
Use within deluge valves & skids applications covered by the manufacturer's technical reference and the approved project design. Confirm the product variant, operating conditions and compatible components before specifying the equipment.
Selection and project integration
Share the system drawings, protected hazard, equipment schedule and project specification with UDCT. Product selection should establish the required flow and pressure, pipework connections, materials, installation orientation and compatible components. Check the precise approval scope for the selected model, size and configuration against the current manufacturer documentation.
The product reference does not replace hydraulic calculations or the approved system design. For foam equipment, confirm the concentrate, proportioning range and discharge-device compatibility as one system. Use the manufacturer instructions for installation, commissioning and maintenance, and confirm the supplied configuration with UDCT before procurement.
