Product overview
The HD Fire Zone Control Manifold Assembly is a component or assembly within the manufacturer's sprinklers & accessories range. The model-specific construction, interfaces and configuration choices are summarized below. Select the equipment together with the compatible valve, sprinkler or system arrangement described in the official technical reference.
Technical specifications
| Manufacturer | HD FIRE PROTECT |
|---|---|
| Product / system | Zone Control Manifold Assembly |
| Product type | Water-Based Systems |
| Product family | Sprinklers & Accessories |
| Subcategory | Sprinklers / Accessories |
| Nominal sizes | 2.5–8 inches |
| Maximum working pressure | 175 psi |
| Included components | Flow switch, test drain, system pressure gauge and pressure relief valve |
| Optional component | Butterfly valve |
Key features
- Nominal sizes: 2.5–8 inches
- Maximum working pressure: 175 psi
- Included components: Flow switch, test drain, system pressure gauge and pressure relief valve
Applications
Use within sprinklers & accessories installations covered by the manufacturer reference. Confirm model compatibility, connections and operating conditions against the approved project design.
Selection and project integration
Share the system drawings, protected hazard, equipment schedule and project specification with UDCT. Product selection should establish the required flow and pressure, pipework connections, materials, installation orientation and compatible components. Check the precise approval scope for the selected model, size and configuration against the current manufacturer documentation.
The product reference does not replace hydraulic calculations or the approved system design. For foam equipment, confirm the concentrate, proportioning range and discharge-device compatibility as one system. Use the manufacturer instructions for installation, commissioning and maintenance, and confirm the supplied configuration with UDCT before procurement.
