Product overview
The Retrotec 450x Commercial Duct Tester System is a measurement system for checking air leakage in ductwork. The fan and pressure measurement arrangement is selected for the duct-test duty, with the published performance table defining the relevant operating range. Use the exact model configuration and power option specified for the project.
Technical specifications
| Manufacturer | RETROTEC |
|---|---|
| Product / system | 450x Commercial Duct Tester System |
| Product type | Testing Equipment |
| Product family | Duct Leakage Testing |
| Subcategory | Commercial Duct Tester |
| Equipment category | Duct air-leakage testing |
| Model / system reference | 450x |
Manufacturer technical data
| Fan Model #: | 400 | |||
| Flow Into Back Pressure of: | CFM | litres/sec | m3/s | |
| Maximum Flow at 120 or 230 VAC: | 1 in WC (250 Pa) | 306 | 144 | 0.144 |
| 4 in WC (1000 Pa) | 302 | 143 | 0.143 | |
| 8 in WC (2000 Pa) | 295 | 140 | 0.14 | |
| Minimum Flow with std Range 18: | 1 in WC (250 Pa) | 7.1 | 12 | 0.00333 |
| Minimum Flow (with opt Range 3): | 0.31 | 0.52 | 0.00014 | |
| Dimensions: | 14″ × 14″ × 26″ (35 x 35 x 66 cm) | |||
| Weight of System: | 21 lb (9.5 kg) | |||
| Flow Accuracy: | +/-5% | |||
| Power input: | 120 V AC, 15.5 A, 50/60 Hz, 1 phase or 240 V AC, 8.5 A, 50/60 Hz 1 phase | |||
| Recommended Fan Calibration Interval: | 5 years | |||
Key features
- Calibrated fan measurement equipment
- Model-specific operating range documented by the manufacturer
- Configuration and power options must match the ordered system
Applications
Air-leakage assessment of ductwork during building-services verification.
Selection and project integration
Share the test specification, expected leakage range, enclosure or duct dimensions and local power supply with UDCT. Selection should establish the appropriate fan arrangement, measuring ranges, adapters, pressure gauge and software licence. Confirm which accessories are included with the ordered kit and which require separate selection.
Testing requires the correct calibration records, a suitable test setup and personnel familiar with the applicable procedure. Use the current manufacturer operating instructions and record the selected configuration in the test report. A quoted equipment range does not replace the conditions and limitations in the technical documentation.
