TECHNICAL PRODUCT
RFII MRI Standard Coverage Sprinklers
Explore technical details, applications and product documentation for this system.
Request product supportPRODUCT OVERVIEW
TECHNICAL REFERENCE & APPLICATION
TYCO Series RFII-MRI is a 5.6 K-factor non-magnetic concealed pendent sprinkler intended for MRI rooms. Quick-response and standard-response configurations combine a discreet cover plate with specialist material selection. Confirm magnetic-field compatibility, listings and installation details in manufacturer data sheet TFP182.
TECHNICAL DATA
PRODUCT SPECIFICATIONS
Key technical data available from the current product reference.
- Manufacturer
- TYCO Fire - Johnson Controls
- Orientation
- Concealed Pendent
- K-Factor
- 5.6
- Temperature Rating
- Up to 200°F
- Response
- Standard, Quick
- Occupancy Type
- Light Hazard, Ordinary Hazard
- Listings & Approvals
- UL and C-UL Listed
- SIN Numbers
- TY3550, TY3530
- Thread
- ½-inch
- Wrench
- RFII
- Note
- See Technical Data Sheet for details
FEATURES
DESIGNED FOR PROJECT INTEGRATION
Key features recorded for this product.
Internally threaded closure with ½ inch (12,7 mm) of adjustment
UL and C-UL Listed
For 5.6 K-factor non-magnetic concealed pendent sprinklers (TY3550, TY3530) see TFP182 for technical information and listing details
TECHNICAL SELECTION
BEFORE SPECIFYING THIS PRODUCT
Confirm the design hazard, required flow and pressure, connection size, installation orientation and the listed or approved configuration. Valve and sprinkler selection must also align with the hydraulic calculation and the maintenance access available on site.
Use this page as an introduction to the recorded product, then verify the current manufacturer documentation and project-specific submittal before procurement. Share the drawing, specification, quantity and location with UDCT for a review of suitability, availability and integration. Explore related product families or request technical support.
