Product overview
SIEX Fixed Hose Stations provide manually applied carbon dioxide suppression from a fixed cylinder and hose-reel arrangement. The manufacturer describes two 67-litre cylinders, a swing-out reel and a trigger-controlled discharge nozzle. The station is intended for local application around the identified equipment hazard and requires the appropriate operator training and site safeguards.
Technical specifications
| Manufacturer | SIEX |
|---|---|
| Product / system | Fixed Hose Stations |
| Product type | Fire Suppression |
| Product family | CO2 Suppression |
| Subcategory | CO2 Systems |
| Extinguishing agent | Carbon dioxide (CO2) |
| Electrical characteristic | Non-conductive agent |
| Residue | No extinguishing residue |
| Cylinder arrangement | Two 67-litre CO2 cylinders |
| Discharge control | Manual application through trigger-controlled nozzle |
| Hose reel | Swing-out arrangement |
Key features
- CO2 extinguishing medium
- Equipment configuration selected for the hazard
- Manufacturer documentation available
Applications
Industrial and equipment hazards within the approved CO2 system design. Carbon dioxide can create a dangerous atmosphere; personnel exclusion, evacuation, alarms and other required safeguards must be addressed in the engineered installation.
Selection and project integration
Share the protected-space drawings, hazard description, equipment schedule and project specification with UDCT. The technical review should establish the selected system configuration, required quantity, installation constraints and interfaces with the detection and control equipment. For gaseous suppression, enclosure integrity, pressure relief, discharge acoustics and personnel safeguards must be assessed as part of the engineered design.
The published model designation is a product reference, not a final bill of materials. Agent quantities, pipe sizing, nozzle selection, storage arrangements and release logic depend on the approved design. Use the current manufacturer instructions for installation, testing and maintenance, and confirm availability with UDCT before procurement.
Manufacturer documents
Official product reference
View this product on the manufacturer website (opens in a new tab)
